16 inch Drawer Slides 6 Pairs (12pcs) Soft Self Close 3 fold Full Extension Ball Bearing Cabinet Drawer Glides Side Mount for Dresser, Cabinet, Kitchen 100 LB Capacity 16" Silver
3 sold in last 24 hours
- [6 pairs Soft Close Drawer Slides]:You will get 6 pairs(12pcs) soft self close drawer slides ,16 inch. And each drawer slides match with 12pcs screws. JI2OOYI self close drawer slides designed with ultra smooth soft-close function. Continuous bearings ensure smooth and quiet performance that offer less noise at closing and opening.
- [Guide for Choosing Size of Drawer Slides]:Side installation.The length of slides can't be longer than the cabinet case depth. Face frame cabinets will require a rear mounting bracket, whereas for faceless cabinets the slides are mounted directly on the side.To determine which size of slides are good for your drawer, please measure the length of the drawer without the frame board. And if the length is not even, please choose 1 inch shorter.
- [High-Grade Material]:All of the drawer slides which made by JI2OOYI are made from high-grade cold rolled steel that is electrom zinc plated.Rust resistant for your lifetime use.Side mounted Steel ball-bearing action.100 LB capacity.
- [3-Fold full extension & Detachable]:The 3-fold full extension allows for the entire drawer to be accessed.Three-stage stretching can pull out the drawer completely.Make full use of your drawer space.There is a plastic buckle on the back of the slide rail, by pressing it,the 3rdtrack(the narrowest section) can be separated.Easy to take down and clean.At the same time,double anti-drop function would prevent drawer separate from cabinets.
- [Application range]: JI2OOYI drawer slides are available in 10inch, 12inch,14inch,16inch,18inch,20inch,22inch.Various choices for drawers in your kitchen,bathroom,bedroom,office with different depth.It also can apply to ,keyboard drawers,wardrobe drawers,wooden or steel drawer,cabinet drawers,toolbox drawers that with demand for big load-bearing capacity.
Tags |
Estimated shipping
Select a product to estimate shipping.10 12 14 16 18 20 22 Inch 100 LB Load Capacity Side Mount Ball Bearing Metal Drawer Slides.
Use on office cabinets,kitchen cabinet, sliding cabinet doors and bathroom cabinets,wardrobe drawers,keyboard,drawers,wooden or steel drawer etc..
extend your drawer to a full open position so that you can access anything in the drawer without reaching under the lip of your cabinet.
Material: High-quality Cold-rolled Steel
Finished:Zinc Plated
There is a plastic buckle on the back of the slide rail, by pressing it,the 3rd track(the narrowest section) can be separated.Easy to take down and clean.
Mouting Method:Side Mounting
Thick/Side Clearance:12.5mm(1/2inch)
drawer slides are available in 10inch,12inch,14inch,16inch,18inch,20inch and 22inch.
Various choices for drawers in your kitchen,bathroom,bedroom,office with different depth.
Measure the depth of your drawers.
Ensure the size of selected drawer tracks ≤ the drawer depth.
Reserve 0.5 inch of space to side mount slides.
Various Applications: shelves, cabinets, industrial drawers, RVs.
Press the release button and pul out the inner rail,Make sure the slides are leveled during the installation process.
Place the base slides stay with the front edge of cabinet,Mount the screws in the permanent mounting holes.
Adjust the inner rail.Mount the screws in the permanent mounting holes.
Two sets of solid steel balls are used inside the ball bearing drawer slide rail,make sure the drawers slide quietly without collision noise.
The drawer slides equipped hydraulic damper which allows the slides achieve soft close effect.
1.2mm high-quality cold-rolled steel, the special electrophoretic coating surface treatment. prevents the slide rail from oxidizing and rusting, and improves corrosion resistance.
Seamless cutting technology, three-point screw hole, strong fixing and bonding force.
Product details
| Main Specification | |
|---|---|
| Included Components | mounting screws or 6 pairs of drawer slides |
| Manufacturer | JI2OOYI |
| Unit Count | 12 Count |
| Brand | JI2OOYI |
| Number of Items | 12 |
| Drawer Type | soft close drawer slides |
| Product Dimensions | 16"L x 1.77"W x 0.47"Th |
| Material | Alloy Steel |
| Colour | Silver |
| Finish Type | Steel |
| Mounting Type | Side Mount |
| Product information | |
| Number of Packs | 6 |
| Technical Details | |
| Maximum Weight Capacity | 100 Pounds |
| Manufacturer Part Number | 16inch-6-S |
| Material Type | Alloy Steel |
| Item details | |
| Model Number | 16inch-6-S |
| Style | |
| Finish Types | Steel |
| Others | |
| Product Type | Drawer Slides |
| Item Dimensions L x W x Thickness | 16"L x 1.77"W x 0.47"Th |
