Relay Board, Relay Module 4 Channel 1 SPDT DIN Rail Mount 24V DC/AC
6 sold in last 24 hours
- About Relay Module: Relay modules is designed to amplify current of output loads. It is mainly used for PLC, microprocessor systems and time relays etc, amplifying the control current of outputs, to protect key control systems not being destroyed
- Product Parameters: Model Number FY-T734C-D24, power source DC, rated voltage 24VAC/DC, rated load current:10A 250VAC/30VDC
- Easy to Install: DIN rail mount, optional 1/2/4 /8/16 channels relay interface, stable and convenient. You could also remove it from the green bracket to make it small enough to fit in narrow space such as the wall
- Easy and Safe to Use: Each relay board is well labeled for clear operation, equipped with LED indicators to allow you to know what relay is working and the signal status, designed with over voltage protection and surge suppression protection for safety
- Customer Service: Please carefully read the specification before ordering to confirm this is the right spec you need. Should you have any questions, please be free to contact us, we will reply within 24 hours
Estimated shipping
Select a product to estimate shipping.Relay Module Board
Voltage:12V
Rated voltage:12VAC/DC
Relay Mounting:Soldered on PCB
Rated Load Current:10A 250VAC/30VDC
Output contact::4 groups, 1NO1NC
Max voltage:110% rated value
Rated current:21.8mA
Coil Resistance:1A 6VDC
Model Number FY-T734-24VACDC
Easy to install
Easy and safe to use
Optional 1/2/4/8/16 channels
Widely used for PLC and microprocessor systems etc.
Equipped with LED indicators to allow you to know what relay is working and the signal status, designed with over voltage protection and surge suppression protection for safety.
Optional 1/2/4/8/16 channels relay interface, stable and convenient. You could also remove it from the green bracket to make it small enough to fit in narrow space such as the wall.
Model Number FY-T734-24VACDC, power source DC, rated voltage 24VAC/DC, rated load current:10A 250VAC/30VDC.
Product details
| Main Specification | |
|---|---|
| Manufacturer | New.Sunny |
| Specification Met | Din |
| Contact Type | Spdt |
| Current Rating | 10 A |
| Brand | GUETNEU |
| UPC | 699838724389 |
| Number of Items | 1 |
| Operation Mode | Automatic |
| Wattage | 24 Watts |
| Connector Type | Through Hole" Or "Surface Mount |
| Coil Voltage | 24 Volts |
| Mounting Type | Din Rail Mount |
| Technical Details | |
| Part Number | XS-SJ-T734C-D24 |
| Contact Current Rating | 10 A |
| Maximum Switching Current | 10 A |
| Maximum Switching Voltage | 24 Volts |
| Minimum Switching Voltage | 24 volts |
| Others | |
| Product Type | Voltage Monitoring Relays |
| Item Highlight | Interface Board(FY-T734C-D24) |
